TYCO V23401-T2G02-E209 V23401-T2G02-E209 V23401-T2G02-E209 V23401-T2G02-E209

 We can sell the products of TYCO at a advantage price

Guang Zhou Lai Jie Electric Co.,LTD

Please contact with “Tommy” for the price

V23401-T2G02-E209

V23401-H2010-B214

V23401-T2010-B222

V23401-H2010-B222

V23401-T2010-B201

V23401-H2010-B201

V23401-T2010-B202

V23401-H2010-B202

V23401-T2014-B214

V23401-H2014-B214

V23401-T2014-B222

V23401-H2014-B222

V23401-T2014-B201

V23401-H2014-B202

V23401-T2014-B202

V23401-T2015-B214

V23401-H2015-B214

V23401-T2015-B222

V23401-H2015-B222

V23401-T2015-B201

V23401-H2015-B201

V23401-T2015-B202

V23401-H2015-B202

V23401-U1016-B101

V23401-U1016-B109

V23401-U1016-B110

V23401-U1016-B133

V23401-U2017-B201

ZRO ... Impedance between R1 and R2 with open outputs ZRS ... Impedance between R1 and R2 with short circuits
between S1 and S3 as well as between S2 and S4

Output impedance
Tolerance: ± 15 % Tolerance: ± 15 %
ZSO ... Impedance between S2 and S4 in a position of 0° ZSS ... Impedance between S1 and S3 in a position of 0°
(minimal coupling) with open outputs (max. coupling) with short circuits between R1 and R2

Transfer function
Pairs of poles p
Transformation ratio rT
rT = VS1-S3 max / VR1-R2
rT = VS2-S4 max / VR1-R2
ü = 0.46 ± 10 % within 4 ... 15 kHz
= 0.46 ± 5 % at 6 kHz
Phase shift ø
VR1-R2(t) = VR1-R2 max · sin(2 · ð · f · t)
VS1-S3(t) = VS1-S3 max · sin(2 · ð · f · t - ø)
for –90° < á < +90°
Tolerance: ± 5°

When choosing the values of these parameters take into
account power dissipation, max. ambient temperature and
the heat dissipation. Including self heating a maximum
operating temperature of 150 °C must not be exceeded.
Generally a power dissipation of P ≤ 0.5 W is not critical.

Input current I
The adjacent figure applies to
VR1-R2 = 6 V.
For other input voltages, the input current
changes follows as:
I = I
Figure · VR1-R2 / 6 V
Power consumption P
The adjacent figure applies to
VR1-R2 = 6 V.
For other input voltages, the power
consumption changes follows as:
P = P
Figure · (VR1-R2 / 6 V)2

Resistance, impedance and operating parameters (continued)
DC resistance
The ohmic resistance values are based on an RR1-R2 = 36 Ω
ambient temperature of 22 °C and change with RS1-S3 = RS2-S4 = 48 Ω
temperature by 0.39 % / K Tolerance: ± 10 %

ZRO ... Impedance between R1 and R2 with open outputs ZRS ... Impedance between R1 and R2 with short circuits
between S1 and S3 as well as between S2 and S4

Output impedance
Tolerance: ± 15 % Tolerance: ± 15 %
ZSO ... Impedance between S2 and S4 in a position of 0° ZSS ... Impedance between S1 and S3 in a position of 0°
(minimal coupling) with open outputs (max. coupling) with short circuits between R1 and R2

Transfer function
Pairs of poles p
Transformation ratio rT
rT = VS1-S3 max / VR1-R2
rT = VS2-S4 max / VR1-R2
ü = 0.5 ± 10 % within 4 ... 20 kHz
= 0.5 ± 5 % at 10 kHz
