Open the "Cross Reference" editor. The updated lists show all of the project objects and places of use of the project. 2. In the list of projects, write the text "tag" in the filter input box above the "Type" column. 3. Select "Used" as filter for the status. 4. Click in the left table and press . All used tags are selected. 5. Click on . The places used for all used tags are displayed in the list of places used. 6. In the list of places used, write the picture name in the filter input box above the "File/Editor" column and press "Enter". 7. Write "StaticText" in the filter input box above the "Object" column and press "Enter". The names of the tags and all places of use are displayed by the filtering.

In the shortcut menu, select the "Go to" command or press the button. The Graphics Designer opens. The static text selected in the list will be selected in the picture. The affected property is displayed in the object properties.

The green lamp in the object properties indicates the dynamics of the property via a tag. 11.Right-click on the green lamp. Select the command "Tag..." to select a different tag already created in the tag selection dialog. 12.The new tag is now linked to the text at this place of use

The following example shows the linking of tags in the WinCC demo project. Customers can use this example or other WinCC projects.

2.The linking of tags is applied in the project by means of the "Apply" button. If the new tags do not exist in the tag management yet, you must create them subsequently.

In Cross Reference you can filter the tags and picture names used in actions. In the pictures you can also link the tags in the actions. To do this, you must structure scripts as follows.

When you create a new action in the Graphics Designer, the corresponding prepared sections will be inserted into the script. You supplement existing scripts accordingly. The SmartTool "WinCC CrossReferenceAssistant" supports you in this.

Reports and logs are created in WinCC to document the configuration data and runtime data. The layouts supplied by WinCC cover most of the cases in which you need to document data. You can edit the supplied layouts or create new ones with the Report Designer. The documentation of the configuration data and runtime data is language-dependent and must be observed for multi-lingual WinCC projects. For more information see the chapter "Logs for multi-lingual projects".

The documentation of configuration data or the project documentation serves to output configuration data of a WinCC project in a report. You can output the reports in all Runtime languages for multi-lingual projects. The documentation of Runtime data or Runtime documentation serves to output process data in a log in Runtime. For multi-lingual projects, the log is output in the currently set Runtime language. The dynamic objects of the Report Designer are used for the Runtime documentation. These dynamic objects are associated with the corresponding applications. The dynamic objects are supplied with the current values during output of the logs. Selection of data for output is application-dependent and is carried out when the layout is created, when the print job is created, or when printing is initiated. The current view or the table content is output in the WinCC V7 controls and the corresponding layouts and print jobs. Report Designer makes print jobs available for outputting the reports and logs. The scheduling, output medium and extent of the output is defined in the print jobs.

The reports and logs can be output: ● with a page layout, ● with a line layout for the message sequence report.

Report Designer provides the page layout editor for editing page layouts. Both the page layouts for the project documentation reports and the logs for Runtime documentation are configured in the page layout editor. Report Designer provides the line layout editor for editing line layouts. You configure the output of the message sequence report in the line layout editor.

It makes sense to begin by configuring the margins of the printable area for the header, footer or a company logo and only then to configure the rest of the printable area for the output of report data. The printable area inside the margins is referred to as the "body of the page

The report and log layout contain a static layer and a dynamic layer. The static layer contains the header and footer of a layout for outputting the company name, company logo, project name, layout name, page number, time, etc. The dynamic layer contains the dynamic objects for outputting the configuration and Runtime data. In the static layer, only static and system objects can be inserted. In the dynamic layer, static and dynamic objects can be inserted. Objects that are inserted in the dynamic part of a page layout are extended dynamically, if required. If an object of the type dynamic table is supplied with data, for example, this table is extended to allow all data in the table to be output. If there are other objects in the dynamic part of the layout, these are moved accordingly. Objects that are to have a fixed position must therefore be inserted in the static part of the layout.
