When choosing the values of these parameters take into
account power dissipation, max. ambient temperature and
the heat dissipation. Including self heating a maximum
operating temperature of 150 °C must not be exceeded.
Generally a power dissipation of P ≤ 0.3 W is not critical

Input current I
The adjacent figure applies to
VR1-R2 = 7 V.
For other input voltages, the input current
changes follows as:
I = I
Figure · VR1-R2 / 7 V

Power consumption P
The adjacent figure applies to
VR1-R2 = 7 V.
For other input voltages, the power
consumption changes follows as:
P = P
Figure · (VR1-R2 / 7 V)2

DC resistance
The ohmic resistance values are based on an
ambient temperature of 22 °C and change with
temperature by 0.39 % / K

ZRO ... Impedance between R1 and R2 with open outputs

Tolerance: ± 15 %
ZSO ... Impedance between S2 and S4 in a position of 0°
(minimal coupling) with open outputs

Tolerance: ± 15 %
ZSS ... Impedance between S1 and S3 in a position of 0°
(max. coupling) with short circuits between R1 and R2

Function
VS1-S3 = +rT · VR1-R2 · cos(p · á)
VS2-S4 = +rT · VR1-R2 · sin(p · á)
p = pairs of poles
This function applies to the clockwise rotation
of the rotor when looking at the (grooveless)
transformer component from the top.

High-voltage test
Windings to housing 500 VAC, 50 Hz
Windings to each other 250 VAC, 50 Hz
Insulation resistance
Windings to housing and Rinsulation > 50 MΩ at 500 VDC
windings to each other
Operating temperature range –55 °C ... +150 °C

Electrical and thermal limits

Momentum of inertia of the rotor approx. 200 g · cm2
Maximum rational speed 20000 rpm
Maximum angular acceleration 64000 rad/s2
Torsional strength of rotor components 1 Nm
Shock resistance (11 ms sine) 1000 m/s2
Vibration fatigue limit (0 ... 2 kHz) 200 m/s2
Permissible radial runout 0.075 mm
(see Dimensioned drawing: Note 1)
Permissible axial offset ± 0.5 mm
(see Dimensioned drawing: Note 2)
