Module internal shared input (MSI) V1.0.0 or higher V13 Update 3 or
higher
(PROFINET IO only)
X
(PROFINET IO only)
Configurable submodules / submodules for
Shared Device
V1.0.0 or higher V13 Update 3 or
higher
(PROFINET IO only)
X
(PROFINET IO only)
You can configure the module with STEP 7 (TIA Portal) and with a GSD fileThe following accessories are supplied with the module and can also be ordered separately
as spare parts:
● Front connector (push-in terminals) including cable tie
● Shield bracket
● Shield terminal
● Power supply element (push-in terminals)
● Labeling strips
● U connector
● Universal front door
For more information on accessories, refer to the system manual Automatmanual Distributed I/O System ET 200MP This section contains the block diagram of the module and outlines various connection
options.
For more information on front connector wiring and creating cable shields, etc., refer to the
"Wiring" section in the Automation System Distributed I/O System ET 200MP You can find additional information on compensating the reference junction temperature in
the function manual Analog value processingrecord in the section Structure of a data record for dynamic reference temperature
(Page 59).
Note
You may use and combine the different wiring options for all channelsThe power supply element is plugged onto the front connector for powering the analog
module. Wire the supply voltage to terminals 41 (L+) and 43 (M). The example in the following figure shows the pin assignment for voltage measurementAnalog digital converter (ADC)
② Backplane bus interface
③ Supply voltage via power supply element
④ Equipotential bonding cable (optional)
Figure 3-2 Block diagram and pin assignment for voltage measurementThe example in the following figure shows the pin assignment for current measurement with
4-wire transmitters.The example in the following figure shows the pin assignment for current measurement with
2-wire transmitterWiring 2-wire transmitter
② Analog digital converter (ADC)
③ Backplane bus interface
④ Supply voltage via power supply element
⑤ Equipotential bonding cable (optional)
Figure 3-4 Block diagram and pin assignment for current measurement with 2-wire transmitterThe example in the figure below shows the pin assignment for 2-wire connection of
resistance sensors or thermal resistors2-wire connection
② Analog digital converter (ADC)
③ Backplane bus interface
④ Supply voltage via power supply element
⑤ Equipotential bonding cable (optional)
Figure 3-5 Block diagram and pin assignment for 2-wire connectionThe example in the figure below shows the pin assignment for 3- and 4-wire connection of
resistance-based sensors or thermal resistors.4-wire connection
② 3-wire connection
③ Analog digital converter (ADC)
④ Backplane bus interface
⑤ Supply voltage via power supply element
⑥ Equipotential bonding cable (optional)
Figure 3-6 Block diagram and pin assignment for 3- and 4-wire connectionThe figure below shows an example of the pin assignment for thermocouples for external or
internal compensation.Wiring of a thermocouple for internal compensation
② Wiring of a thermocouple for external compensation
③ Analog digital converter
④ Backplane bus interface
⑤ Supply voltage via power supply element
⑥ Equipotential bonding cable (optional)
Figure 3-7 Block diagram and pin assignment for the thermocoupleThe following figure shows an example of the pin assignment for grounded thermocouples
for internal compensation.Wiring of a thermocouple (grounded) for internal compensation
② Analog digital converter (ADC)
③ Backplane bus interface
④ Supply voltage via power supply element
⑤ Equipotential bonding cable (optional)
Figure 3-8 Block diagram and pin assignment for grounded thermocoupThe module is set to voltage measurement type with measuring range ±10 V by default. You
need to reassign the module parameters with STEP 7 if you want to use a different
measurement type or range.
Deactivate the input if it is not going to be used. The module cycle time is shortened and the
interference factors that lead to failure of the module (for example, triggering a hardware
interrupt) are avoided.
Measurement types and ranges
The following table shows the measurement types and the respective measuring range.
Table 4- 1 Measurement types and rangesCurrent 2WMT
(2-wire transmitter)
4 mA to 20 mA
Current 4WMT
(4-wire transmitter)
