Size of the motor starter max. size 5 to NEMA
Power No. of switching cycles
(typical)
Lamp load (230 V AC) 1000 W
1500 W
25000
10000
Energy-saving lamps/fluorescent lamps with electronic ballast3) 10 x 58 W 25000
Fluorescent lamps, conventionally compensated 1 x 58 W 25000
Fluorescent lamps, non-compensated 10 x 58 W 25000
Contact protection RC quenching element; 330 Ω, 0.1 µF
Wiring two outputs in parallel
• for redundant load control supported (only outputs with the same load voltage)
• for performance increase not supported
Control of a digital input supported
Switching frequency
• Mechanical max. 10 Hz
• with resistive load max. 2 Hz
• with inductive load to IEC 947-5-1, DC13/AC15 max. 0.5 Hz
• with lamp load max. 2 Hz
Wiring of the actuators using a 40-pin front connector
1) Without inserted jumper (SJ).
2) With AC load voltage and inserted jumper (SJ). No residual current if the jumper (SJ) is not installed.
3) The sum of all inrush currents on a ballast connected to an output must not
exceed 5 A.
The residual current of an RC quenching element connected to IEC Type 1 inputs may
cause unwanted signal states. Remove the SJ jumper to rectify this fault.
Configuration in RUN
Special considerations must be given if you use the Configuration in RUN function.
SF LED is lit:
Status before re-configuration diagnostics on, SF LEDs lit among others (on CPU, IM or
module), although diagnostics are no longer pending and the module is operating correctly.
Solution:
● Only change the configuration when no diagnostics are pending for the module or
● Pulling and plugging the module.

The table below provides an overview of configurable parameters and defaults for SM 322;
DO 8 x Rel. AC 230V/5A.
The defaults apply if you have not set any parameters in STEP 7.

Enable
• Diagnostic interrupts yes/no no Dynamic Module
Reaction to CPU STOP Set substitution value (SSV)
Hold last value (HLV)
SSV Dynamic Channel
Set substitution value "1" yes/no no Dynamic Channel

The table below provides an overview of the diagnostic messages of
SM 322; DO 8 x Rel. AC 230V/5A.
Table 3- 36 Diagnostics messages of SM 322; DO 8 x Rel. AC 230V/5AWatchdog time-out generally infrequent high level of electromagnetic
nterferenceEliminate interference and cycle theCPU power supply off and onDefective module Replace themoduleEPROM error generally infrequent high level of electromagneticinterferenceEliminate interferenceand cycle theCPU power supply off and onDefective module Replace the moduleRAM error generallytransient high electromagneticinterference
Eliminate interference and cycle the
CPU power supply off and on
Defective module Replace the moduleThe SM 322; DO 8 x Rel. AC 230V/5A can trigger diagnostic interrupts.For detailed information on the OBs and SFCs mentioned below, refer to the STEP 7 Online
Help.Enabling interrupts
here is no default interrupt setting, i.e. interrupts are disabled if not set accordingly.Program the interrupt enable parameter in STEP 7.
Diagnostic interruptIncoming error events (initial occurrence) and outgoing error events (error is cleared) arereported by means of diagnostics interrupt, if this interrupt is enabled.The CPU interrupts user program execution in order to process diagnostics interrupt OB82.You can call SFC51 or 59 in OB82 in the user program to obtain detailed diagnostics datafrom the module.Diagnostics data remain consistent until the program exits OB82. The module acknowledges
the diagnostics interrupt when the program exits OB82.6AG1322-1HF10-2AA0PropertiesThe SM 322; DO 8 x Rel. 230 V AC / 5 A is characterized by the following properties:● 8 outputs, electrically isolated in groups of 1● Rated load voltage 24 to 120 V DC, 48 V to 230 V AC

uitable for AC/DC solenoid valves, contactors, motor starters, FHP motors and signal
lamps.
Always use connecting cables with a cross-section of 1.5 mm2 when operating with switching
currents > 3 A in order to reduce any temperature rise in the connector area of the module to
a minimum
Channel number
② Status displays - green
③ Backplane bus interface
④ Options of looping the power supply to contacts
Make allowances for the special feature outlined below when operating relay output module
322-1HF10 on SELV:
