TAMAGAWA TS5013N63 TS5013N63 TS5013N63 TS5013N63 TS5013N63 TS5013N63

TS5013N63

 We can sell the products of Tamagawa at a Advantage price

Guang Zhou Lai Jie Electric Co.,LTD

Please contact with “Tommy” for the price

TS5214N561

TS5214N510

TS2014N182E32

TS3653N2E5

TS5320N510

TS5016N60

TS5016N60

TS2651N111E78

TS2014N181E32

TS5208N130

TS5214N566

TS5205N450

TS5205N454

TS2651N11E78

TS2651N141E78

TS2651N1E78

TS2651N131E78

TS5016N60

TS5013N60

TS5208N130

TS5246N160

TS5246N164

TS2650N1E78

TS2650N11E78

TS2650N101E78

TS5212N500

TS5308N616

TS5314N616

TS2640N671E110

TS2605N1E64

TS2640N71E10

TS4503N2000E100

TS4503N2000E200

TS5205N456

TS5205N450

TS5205N454

TS1981N56E19

TS1981N56E18

TS2651N111E78

TS2651N181E78

TS2640N321E64

TS5214N566/N8566

TS5208N8566

TS5667N120

TS5667N420

TS2651N181E78

TS2651N141E78

TS6026N151

TA8481N0300

TA8480N0100

TA8480N0200

TS5000N632

TS2014N181E32

TS2651N131E78

TS5667N420

TS5303N510

For information on installation and wiring, refer to the , CPU 31xC, and CPU 31x
Operating Instructions: Installation. The operating instructions are available on the Internet

Further information
The structure of parameter sets (data records 0, 1 and 128) is described in the system data
section of the appendix. You must be familiar with this structure if you want to modify module
parameters in the STEP 7 user program.
The structure of diagnostic data (data records 0 and 1) is described in the system data
section of the appendix. You must be familiar with this structure if you want to analyze
diagnostics data of the modules in the STEP 7 user program.
See also
Principles of programming signal modules in the user program (Page 522)
Evaluating diagnostic data of signal modules in the user program (Page 583)Digital modules3.1 Module overviewModule dataManual, 06/2017, A5E00105505-AJ 493.1 Module overview
IntroductionThe tables below summarize the essential properties of the digital modules. This overview
supports you in selecting a module to suit your requirements.
3.1.1 Digital input modules:
Overview of properties
The table below shows essential properties of the digital input modules
Table 3- 1 Digital input modules:Number of outputs 64 DO; isolated ingroups of 1664 DO; isolated ingroups of 1632 DO; isolated ingroups of 832 DO; isolated in
 of 816 DO; isolated ingroups of 8Output current 0.3 A 0.3 A 0.5 A 1.0 A 0.5 A
Rated load voltage 24 V DC 24 V DC 24 V DC 24 V DC 24 V DCSuitable for... solenoid valves, DC contactors and signal lampsSupports isochronousmodeno no No No NoProgrammable
diagnosticsNo No No No noDiagnostic interrupt No No No No NoSubstitute valueoutput
No No No No NoSpecial features -
Digital modules3.1 Module overviewModule dataManual, 06/2017, A5E00105505-AJ 53
Table 3- 5 Digital output modules (continued)Properties
ModuleSM 322; DO 16 xDC24V/0,5A High
Speed(-1BH10-)
SM 322; DO 16 xUC24/48 V
(-5GH00-)SM 322; DO 16 x
AC120/230V/1A(-1FH00-)
SM 322; DO 16 xDC24V/0,5A
(-8BH00-)*

-8BH01-) *
(-8BH10-)
SM 322; DO 8 x
DC24V/2A
(-1BF01-)
Number of outputs 16 DO; isolated in
groups of 8
16 DO; isolated in
groups of 1
16 DO; isolated in
groups of 8
16 DO; isolated in
groups of 4
8 DO; isolated in
groups of 4
Output current 0.5 A 0.5 A 1 A 0.5 A 2 A
Rated load voltage 24 V DC 24 to 48 V DC
24 to 48 V AC
120/230 V AC 24 V DC 24 V DC
Suitable for... solenoid valves, DC contactors and signal lamps
Supports isochronous
mode
Yes no no no no
Programmable
diagnostics
No Yes no yes no
Diagnostic interrupt no Yes No Yes No
Substitute value output Yes No
Special features Fast module;
especially for
isochronous
mode
- - Redundant load
control is supported;
extensive
control functions
-
Digital modules
3.1 Module overview
Module data
54 Manual, 06/2017, A5E00105505-AJ
Table 3- 6 Digital output modules (continued)
Properties
Module
SM 322; DO 8 x
DC24V/0,5A with
diagnostics interrupt
(-8BF00-)
SM 322; DO 8 x
DC48-125V/1,5A
(-1CF00-)
SM 322; DO 8 x
AC120/230 V/2A
(-1FF01-)
SM 322;DO 8 x
AC120/230 V/ 2A
ISOL
(-5FF00-)
Number of outputs 8 DO; isolated in
groups of 8
8 DO; electrically isolated
in groups of 4,
with reverse polarity
protection
8 DO; isolated in
groups of 4
8 DO; isolated in
groups of 1
Output current 0.5 A 1.5 A 2 A 2 A
Rated load voltage 24 V DC 48 to 125 V DC 120/230 V AC 120/230 V AC
Suitable for... solenoid valves, DC contactors and signal
lamps
AC solenoid valves, contactors, motor starters,
FHP motors and signal lamps.
Supports isochronous
mode
No No No No
Programmable
diagnostics
Yes No no yes
Diagnostic interrupt Yes No no yes
Substitute value output Yes No no yes
Special features Redundant load control
is supported
- Fuse blown display.
Replaceable fuse for
each group
-
* This module is described in the ET 200M Signal Modules for Process Automation manual.
You can find the manual on the Internet

The table below shows the essential properties relay output modules
Number of outputs 16 outputs, electrically
isolated in groups of 8
8 outputs, electrically
isolated in groups of
2
8 outputs, electrically
isolated in groups of
1
8 outputs, electrically
isolated in groups of
1
Rated load voltage 24 VDC to 120 VDC,
48 VAC to 230 VAC
24 VDC to 120 VDC,
48 VAC to 230 VAC
24 VDC to 120 VDC,
24 VAC to 230 VAC
24 VDC to 120 VDC,
48 VAC to 230 VAC
Suitable for... AC/DC solenoid valves, contactors, motor starters, FHP motors and signal lamps
The table below shows the essential properties of digital IO modules
Table 3- 8 Digital IO modules
Properties Module
SM 323; DI 16/DO 16 x
DC 24 V/ 0,5 A
(-1BL00-)
SM 323; DI 8/DO 8 x
DC 24 V/0,5 A
(-1BH01-)
SM 327; DI 8/DX 8 x
DC 24 V/0,5 A,
Programmable
(-1BH00-)
Number of inputs 16 inputs, electrically isolated
in groups of 16
8 inputs, electrically isolated
in groups of 8
8 digital inputs, plus 8 separately
programmable inputs/outputs,
electrically
isolated in groups of 16
Number of outputs 16 outputs, electrically isolated
in groups of 8
8 outputs, electrically isolated
in groups of 8
Rated input voltage 24 VDC 24 VDC 24 VDC
Output current 0.5 A 0.5 A 0.5 A
Rated load voltage 24 VDC 24 VDC 24 VDC
Inputs suitable for... Switches and 2-/3-/4-wire proximity switches (BEROs).
Outputs suitable for... solenoid valves, DC contactors and signal lamps
Supports isochronous mode no no no
Programmable diagnostics no no no
Diagnostic interrupt no no no
Edge-triggered hardware interrupt
no no no
Programmable input delay no no no
Substitution value output no no no
Special features - 8 individually configurable
input or outputs;
Reading back of inputs is
possible, for example, for
diagnoses
Digital modules
3.2 Steps in selecting and commissioning the digital module
Module data
Manual, 06/2017, A5E00105505-AJ 57
3.2 Steps in selecting and commissioning the digital module
Introduction
The table below contains the steps required to successfully complete commission of digital
modules.
You do not strictly have to adhere to this suggested sequence, that is, you can complete
other tasks such as installing or commissioning other modules, or program the module at an
earlier or later time.
Step sequence
Table 3- 9 Steps in selecting and commissioning the digital module
Step Procedure See...
1. Selecting the module Chapter Modules overview (Page 49)and the specific modulechapter
2. Installing the module in the SIMATIC S7systemInstallation chapter in the relevant AS Installation Manual:
• Automation System, Hardware and Installation, or S7-400 / M7-400 Automation System, Hardware and Installationor• Distributed I/O Device ET 200M3. Assigning module parameters Chapter Diagnostics ofdigital modules (Page 59)4. Commission the configuration Commissioning chapter in the relevant installation manual:of the
AS used:
• Automation System, Hardware and Installation, or S7-
400 / M7-400 Automation System, Hardware and Installation
or
• ET 200M distributed I/O device
5. Analysis the configuration if commissioning
was not successful.
Chapter Diagnostics of digital modules (Page 59)
See also
Programming digital modules (Page 58)
Parameters of digital output modules (Page 528)
Module overview (Page 49)
Digital modules
3.3 Programming digital modules
Module data
58 Manual, 06/2017, A5E00105505-AJ
3.3 Programming digital modules
Introduction
Digital modules may have different properties. You can program the properties of certain
modules.
All information in this chapter applies only to programmable digital modules:
● Digital input module SM 321; DI 16 x DC 24 V with process and diagnostic interrupts,
isochronous; (6ES7321-7BH01-0AB0)
● Digital input module SM 321; DI 16 x DC 24 V/125 V with process and diagnostic
interrupts (6ES7321-7EH00-0AB0)
● Digital output module SM 322; DO 16 x DC 24 V/0,5 A (6ES7322-8BH10-0AB0)
● Digital output module SM 322; DO 8 x DC 24 V/0,5 A with diagnostic interrupt
(6ES7322-8BF00-0AB0)
● Digital output module SM 322; DO 8 x AC120/230 V /2A ISOL (6ES7322-5FF00-0AB0)
● Digital output module SM 322; DO 8 x Rel. AC230V /5A (6ES7322-5HF00-0AB0)
● Digital input/output module SM 327; DI 8/DO 8 x DC 24 V/0,5 A (6ES7327-1BH00-0AB0)
Programming tools
Only program the digital modules in STEP 7 while the CPU is in STOP.
After you defined all parameters, download these from your PG to the CPU. During its STOP
→ RUN transition, the CPU transfers the parameters to the relevant digital modules.
Static and dynamic parameters
Parameters are organized by static and dynamic properties.
Set the static parameters while the CPU is in STOP, as described earlier.
You may also edit dynamic parameters in the active user program of an S7 PLC using SFCs.
However, the parameters set in STEP 7 will be applied again after a RUN → STOP, STOP →
RUN transition of the CPU. The appendix Parameter sets of the signal modules (Page 522)
describes the assignment of module parameters in the user program.
Parameters programmable using CPU operating state
static PG (STEP 7 HW CONFIG) STOP
dynamic PG (STEP 7 HW CONFIG) STOP
SFC55 in the user program RUN
Parameters of digital modules
Information on programmable parameters is available in the module-specific chapt

The information provided in this chapter applies only to digital modules with
diagnostics functions.
● Digital input module SM 321; DI 16 x DC 24 V with process and diagnostic interrupts,
isochronous; (6ES7321-7BH01-0AB0)
● Digital input module SM 321; DI 16 x DC 24 V/125 V with process and diagnostic
interrupts (6ES7321-7EH00-0AB0)
● Digital output module SM 322; DO 16 × UC 24/48 V (6ES7322-5GH00-0AB0)
● Digital output module SM 322; DO 16 x DC 24 V/0,5 A (6ES7322-8BH10-0AB0)
● Digital output module SM 322; DO 8 x DC 24 V/0,5 A with diagnostic interrupt
(6ES7322-8BF00-0AB0)
● Digital output module SM 322; DO 8 x AC120/230 V /2A ISOL (6ES7322-5FF00-0AB0)
● Digital output module SM 322; DO 8 x Rel. AC230V /5A (6ES7322-5HF00-0AB0)
Programmable and non-programmable diagnostics messages
We distinguish between programmable and non-programmable diagnostics messages.
You only obtain programmable diagnostics messages if you have enabled diagnostics at the
relevant parameters. Program the "Diagnostics" parameter block in STEP 7.
Digital modules always return non-programmable diagnostics messages, irrespective of
diagnostics being enabled.
Reactions to diagnostics message in STEP 7
Actions initiated by diagnostics messages:
● The diagnostics message will be entered in the diagnostics data of the digital module,
and is then passed to the CPU.
● The SF LED on the digital module is lit.
● When "Enable Diagnostics Interrupt" is set in STEP 7, the system triggers a diagnostics
interrupt and calls OB82

Reading diagnostics messages
You can read detailed diagnostics messages using SFCs in the user program (refer to the
appendix Diagnostics data of signal modules (Page 583)).
In STEP 7, you can view the cause of error by reading the module diagnostics data (refer to
the STEP 7 Online Help.)
Digital modules
3.4 Diagnostics of digital modules
Module data
60 Manual, 06/2017, A5E00105505-AJ
Diagnostics message using the SF LED
Digital modules with diagnostics function indicate errors at their SF LED (group error LED.)
The SF LED lights up when the digital module generates a diagnostics message. It goes
dark after all error states are cleared.
The SF LED also lights up to indicate external errors (short-circuit at the sensor supply),
regardless of the CPU operating state (at POWER ON.)
Diagnostics messages and interrupt processing of digital modules
For information on diagnostics messages, their possible causes, troubleshooting measures,
and possible interrupts refer to the specific module chapter.
Overvoltage occurs when an inductance is deactivated. Examples of this are relay coils and
contactors.
Integrated overvoltage protection
The digital output modules of have integrated overvoltage protection equipment.
Extra overvoltage protection
Inductances should only be configured with extra overvoltage protection equipment in the
following instances:
● If SIMATIC outpu

t current circuits can be deactivated by extra fitted contacts (e.g. relay
contacts).
