Backplane bus interface
Digital modules
3.13 Digital input module SM 321; DI 16 x DC 24 V; source input; (6ES7321-1BH50-0AA0)
Module data
104 Manual, 06/2017, A5E00105505-AJ
SM 321; DI 16 x DC 24 V - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight ca. 200 g
Module-specific data
Supports isochronous mode no
Number of inputs 16
Cable length
• unshielded
• shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Number of simultaneously controlled inputs
• horizontal mounting position
to 60 °C
16
• vertical mounting position
to 40 °C
16
Electrical isolation
• between channels and the backplane bus yes
• between channels
in groups of
yes
16
Isolation test voltage 500 V DC
Current consumption
• from the backplane bus max. 10 mA
Power loss of the module typ. 3.5 W
Status, interrupts, diagnostics
Status display green LED per channel
Interrupts none
Diagnostic functions none
Encoder selection data
Input voltage (reference potential L+)
• Rated value
• "1" signal
• "0" signal
24 V DC
-13 V to -30 V
+30 V to -5 V
Input current
• "1" signal typ. 7 mA
Input delay
• "0" to "1" transition
• "1" to "0" transition
1.2 ms to 4.8 ms
1.2 ms to 4.8 ms
Input characteristics to IEC 61131, type 1
Connection of 2-wire BEROs
• Permissible quiescent current
supported
max. 1.5 mA
Wiring of the signal transmitters using a 20-pin front connector
Digital input module SM 321; DI 16 x UC 24/48 V;
(6ES7321-1CH00-0AA0)
Order number
6ES7321-1CH00-0AA0
Properties
Properties of SM 321; DI 16 x UC24/48 V:
● 16 inputs, electrically isolated
● Electrical isolation between channels of 120 V AC
● Rated input voltage 24 VDC/VAC to 48 VDC/VAC
● Inputs are autarkic and can be wired to suit any configuration
Wiring and block diagram of SM 321; DI 16 x UC 24/48 V
① Channel number
② Status display - green
③ Backplane bus interface
Digital modules
3.14 Digital input module SM 321; DI 16 x UC 24/48 V; (6ES7321-1CH00-0AA0)
Module data
106 Manual, 06/2017, A5E00105505-AJ
SM 321; DI 16 x UC 24/48 V - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D 40 x 125 x 117
Weight ca. 260 g
Module-specific data
Supports isochronous mode no
Number of inputs 16
Cable length
• unshielded
• shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Number of simultaneously controlled inputs
• horizontal mounting position up to 60 °C 16
• other mounting positions up to 40 °C 16
Electrical isolation
• Between channels and the backplane bus Yes
• between channels
In groups of
Yes
1
Maximum potential difference
• Between channels and the backplane bus 170 VDC, 120 VAC
• between inputs of different groups 170 VDC, 120 VAC
Isolation test voltage
• Between channels and the backplane bus 1500 VAC
• between inputs of different groups 1500 VAC
Current consumption
• from the backplane bus 100 mA max.
Power loss of the module
• Operation with 24 V
• Operation with 48 V
typ. 1.5 W
typ. 2.8 W
Status, interrupts, diagnostics
Status display
Interrupts
Diagnostic functions
green LED per channel
none
none
Digital modules
3.14 Digital input module SM 32
Input voltage
• Rated value 24 VDC/VAC or 48 VDC/VAC
• "1" signal
• "0" signal
• Frequency band
14 V to 60 V
-5 V to 5 V
0 Hz to 63 Hz
Input current
• "1" signal
• "0" signal
typ. 2.7 mA
-1 mA to +1 mA
Input delay
• "0" to "1" transition
• "1" to "0" transition
max. 16 ms
max. 16 ms
Input characteristics to IEC 61131, type 1
Connection of 2-wire BEROs supported
• Permissible quiescent current max. 1 mA
Wiring of the signal sensors using a 40-pin front connector
Digital modules
3.15 Digital input module SM 321; DI 16 x DC 48-125 V; (6ES7321-1CH20-0AA0)
Module data
108 Manual, 06/2017, A5E00105505-AJ
3.15 Digital input module SM 321; DI 16 x DC 48-125 V;
(6ES7321-1CH20-0AA0)
Order number: "Standard module"
6ES7321-1CH20-0AA0
Order number: "SIPLUS module"
6AG1321-1CH20-2AA0
Properties
Properties of SM 321; DI 16 x DC 48-125 V:
● 16 inputs, electrically isolated in groups of 8
● Rated input voltage 48 VDC to 125 VDC
● suitable for switches and 2- /3-/4-wire proximity switches (BEROs)
Wiring and block diagram of SM 321; DI 16 x DC 48-125 V
① Channel number
② Status display - green
③ Backplane bus interface
Digital modules
3.15 Digital input module SM 321; DI 16 x DC 48-125 V; (6ES7321-1CH20-0AA0)
Module data
Manual, 06/2017, A5E00105505-AJ 109
SM 321; DI 16 x DC 48-125 V - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 120
Weight ca. 200 g
Module-specific data
Supports isochronous mode no
Number of inputs 16
Cable length• unshielded
• shieldedmax. 600 mmax. 1000 m
Voltages, currents, electrical potentialsNumber of simultaneously controlled inputs per group at UI to 60 Vto 146 V• horizontal mounting position
to 50 °Cto 60 °C
8
86
• vertical mounting positionto 40 °C
8 8Electrical isolation• between channels and the backplane bus yes• between channels
in groups ofyes8Maximum potential difference• between different circuits 146 VDC / 132 VACIsolation test voltage 1500 VDCCurrent consumption• from the backplane bus max. 40 mAPower loss of the module typ. 4.3 WStatus, interrupts, diagnosticsStatus display green LED per channel
Interrupts nonDiagnostic functions noneDigital modules
3.15 Digital input module SM 321; DI 16 x DC 48-125 V; (6ES7321-1CH20-0AA0)Module data110 Manual, 06/2017, A5E00105505-AJTechnical specificationsSensor selection dataInput voltage• Ratedvalue 48 VDC to 125 VDC
• "1" signal 30 V to 146 • "0" signal -146 V to 15 V
